FG16OR16 - Power cable insulated with high quality EPM-rubber, with PVC sheath, not propagating fire, with reduced corrosive gas emission
Item descriptions
| Application: | This power cable is suitable for fixed installations, preferably in cable ducts, indoors, outdoors, in water or underground if no mechanical damage is to be expected |
| Construction: | 1 ..... fine wired copper conductor, class 5 2 ..... rigid EPM rubber, G16 quality 3 ..... thermoplastic compound, fire resistend, non water absorbing 4 ..... anti abrasive PVC compound R15 quality, fire resistend, reduced wather permeability |
| Information: | at short circuit of max. 5 sec. <=250 mm² --> 250°C >250 mm² --> 220°C |
| Standards: | CEI 20-13 IEC 60502-1 CEI UNEL 35318 (cables with 1-5 cors) CEI UNEL 35322 (signal, with 6 and more cors) |
Technical data:
| Nominal voltage Uo/U | [V] | 600 / 1000 Volt | |
| Test voltage | [V]AC | 4000 | |
| Temperature range | in motion | - 0°C do +90°C | |
| fixed | -15°C do +90°C | ||
| Bending radius | x diameter | 4 | |
| signal | x diameter | 6 | |
| Flammability | standard | EN 60332-1-2 |
| Number of cores and nominal cross section mm² | Copper figure kg/km | Overall diameter max mm | Weight cca kg/km | Current carrying capacity ground A | Current carrying capacity air A |
| 1 x 1,5 | 14,4 | 8,2 | 55 | 21 | 24 |
| 1 x 2,5 | 24 | 8,7 | 66 | 27 | 33 |
| 1 x 4 | 38,4 | 9,3 | 84 | 35 | 45 |
| 1 x 6 | 57,6 | 9,9 | 110 | 44 | 58 |
| 1 x 10 | 96 | 10,9 | 150 | 59 | 80 |
| 1 x 16 | 153,6 | 11,4 | 220 | 77 | 107 |
| 1 x 25 | 240 | 13,2 | 310 | 100 | 135 |
| 1 x 35 | 336 | 14,6 | 410 | 121 | 169 |
| 1 x 50 | 480 | 16,4 | 560 | 150 | 207 |
| 1 x 70 | 672 | 18,3 | 760 | 184 | 268 |
| 1 x 95 | 912 | 20,4 | 960 | 217 | 328 |
| 1 x 120 | 1152 | 22,4 | 251 | 383 | |
| 1 x 150 | 1440 | 24,8 | 287 | 444 | |
| 1 x 185 | 1776 | 27 | 323 | 510 | |
| 1 x 240 | 2304 | 30,2 | 379 | 607 | |
| 1 x 300 | 2880 | 33 | 429 | 703 | |
| 1 x 400 | 3840 | 36,5 | 500 | 823 |
| Number of cores and nominal cross section mm² | Copper figure kg/km | Overall diameter max mm | Weight cca kg/km | Current carrying capacity ground A | Current carrying capacity air A |
| 2 x 1,5 RE | 28,8 | 12 | 130 | 23 | 26 |
| 2 x 2,5 RE | 48 | 13 | 165 | 30 | 36 |
| 2 x 4 RE | 76,8 | 14,2 | 210 | 39 | 49 |
| 2 x 6 RE | 115,2 | 15,4 | 270 | 49 | 63 |
| 2 x 10 RE | 192 | 17,3 | 390 | 66 | 86 |
| 2 x 16 RM | 307,2 | 19,4 | 520 | 86 | 115 |
| 3 x 1,5 RE | 43,2 | 12,5 | 150 | 19 | 23 |
| 3 x 2,5 RE | 72 | 13,6 | 190 | 25 | 32 |
| 3 x 4 RE | 115,2 | 14,9 | 250 | 32 | 42 |
| 3 x 6 RE | 172,8 | 16,2 | 320 | 41 | 54 |
| 3 x 10 RE | 288 | 18,2 | 470 | 55 | 75 |
| 3 x 16 RE | 460,8 | 20,6 | 640 | 72 | 100 |
| 3 x 25 RM | 720 | 24,5 | 960 | 93 | 127 |
| 3 x 35 SM | 1008 | 27,3 | 114 | 158 | |
| 3 x 50 SM | 1440 | 31,2 | 141 | 192 | |
| 3 x 70 SM | 2016 | 35,6 | 174 | 246 | |
| 3 x 95 SM | 2736 | 40 | 206 | 298 | |
| 3 x 120 SM | 3456 | 44,4 | 238 | 346 | |
| 3 x 150 SM | 4320 | 49,5 | 272 | 399 | |
| 3 x 35/25 | 1248 | 29,2 | 114 | 158 | |
| 3 x 50/25 | 1680 | 32,4 | 141 | 192 | |
| 3 x 70/35 | 2352 | 37 | 174 | 246 | |
| 3 x 95/50 | 3216 | 42 | 206 | 298 | |
| 3 x 120/70 | 4128 | 46,9 | 238 | 346 | |
| 3 x 150/95 | 5232 | 52,5 | 272 | 399 | |
| 4 x 1,5 | 57,6 | 13,4 | 170 | 19 | 23 |
| 4 x 2,5 | 96 | 14,6 | 220 | 25 | 32 |
| 4 x 4 | 153,6 | 16 | 295 | 32 | 42 |
| 4 x 6 | 230,4 | 17,5 | 385 | 41 | 54 |
| 4 x 10 | 384 | 19,8 | 575 | 55 | 75 |
| 4 x 16 | 614,4 | 22,4 | 795 | 72 | 100 |
| 4 x 25 | 960 | 26,8 | 93 | 127 |
| Number of cores and nominal cross section mm² | Copper figure kg/km | Overall diameter max mm | Weight cca kg/km | Current carrying capacity ground A | Current carrying capacity air A |
| 5 x 1,5 RE | 72 | 14,4 | 195 | 19 | 23 |
| 5 x 2,5 RE | 120 | 15,6 | 260 | 25 | 32 |
| 5 x 4 RE | 192 | 17,3 | 345 | 32 | 42 |
| 5 x 6 RE | 288 | 18,9 | 455 | 41 | 54 |
| 5 x 10 RE | 480 | 21,5 | 680 | 55 | 75 |
| 5 x 16 | 768 | 24,4 | 970 | 72 | 100 |
| 5 x 25 | 29,3 | 93 | 127 | ||
| 5 x 35 | 32,8 | 114 | 158 | ||
| 5 x 50 | 38,2 | 141 | 192 | ||
| 7 x 1,5 RE | 100,8 | 15,4 | 260 | 16 | 13 |
| 10 x 1,5 RE | 144 | 18,7 | 340 | 16 | 13 |
| 12 x 1,5 RE | 172,8 | 19,3 | 380 | 12,5 | 11 |
| 16 x 1,5 RE | 230,4 | 21,1 | 480 | 12,5 | 11 |
| 19 x 1,5 RE | 273,6 | 22,1 | 535 | 11,5 | 9 |
| 24 x 1,5 RE | 345,6 | 25,4 | 640 | 11,5 | 9 |
| 7 x 2,5 RE | 168 | 16,8 | 381 | 21 | 17,5 |
| 10 x 2,5 RE | 240 | 20,6 | 462 | 21 | 17,5 |
| 12 x 2,5 RE | 288 | 21,3 | 530 | 17,5 | 13,5 |
| 16 x 2,5 RE | 384 | 23,3 | 670 | 17,5 | 13,5 |
| 19 x 2,5 RE | 456 | 24,5 | 755 | 14 | 12 |
| 24 x 2,5 RE | 576 | 28,3 | 915 | 14 | 12 |
